NVMe Storage for Backup Targets

Introduction

I’ve used NVMe disks on a modest scale already for code build servers, SQL Server deployments (physical or virtual) and basically for any workload where the benefits of better storage performance outweigh the loss of high availability (clustering, live migration) such as workstation use, I can run a pretty nice lab on my workstation and not feel miserable due to disk IO contention.

For the price you pay and the problems they solve, the performance benefits of NVMe are a great deal. Just run Windows Server 2016 with nested Hyper-V on an NVME as a developer with a dozen VMs for AD, IIS, Middle ware and SQL Server. You’ll see what it means. Anything less than 8 cores, DDR 4 and a modern motherboard need not apply by the way.

We’re looking forward to NVMe deployments where high available storage is available (shared or shared nothing) for virtualized workloads. We’re seeing the first examples of this in certain Storage Spaces Direct deployments with Windows 2016. I’m pretty sure the industry will push NVMe usage to new heights for use in such scenarios the coming years with NVMe Fabrics.

Recently we’ve been looking at NVMe disks as a high performant backup tier in our backup storage targets. Yup, read on. Sometimes I get this crazy idea I need to scratch, or better, test out in the lab.

NVMe Storage for Backup Targets

When needed you can build pretty solid backup target with cheap, “high capacity” SATA SSDs as well. The thing is that you’ll be limited by the capabilities of SATA itself. You also need decent controllers leading to costs associated with mitigating those. SATA isn’t exactly the best choice for high throughput, concurrent workloads either. You can move up to SAS in order to go beyond the limits of SATA for SSD but the cost goes up accordingly.

When it comes to cost versus performance, that’s where PCIe shines brighter than anything we have today. Sure it’s not yet feasible to do so for large data volumes but we’re not looking at this for the bulk of our VMs or data. We’re looking a use case where we need stellar performance in a reasonable volume we can drop into a server.

Some people will shout in a visceral reaction (*) that I’m nuts spending that amount of money on backup storage. Well no, I’m not. You have to look at the needs of the use case and the economics of achieving a solution. For a company that has the need to back up a number of state full virtual machines every 10 minutes and want to keep 12-24 or so restore points around NVMe disks can deliver a very cost effective solution. You’re probably running those VMs high available, shared tier 1 storage already, the cost of which is a multitude of a couple of NVMe disks. Let’s look at an example. Say we’re leveraging Scale-Out Repositories with Veeam Backup and Replication and we have 3 to 4 repositories. Dropping 1 or 2 NVME disks to every node can deliver 6 to 8 TB of stellar performance to your existing setup. In many of my deployments we get all the other resources in those nodes cost effectively because we typically recycle our Hyper-V hosts. So cores, memory and bandwidth are plentiful without huge investments in new dedicated servers. If you do buy some of the high density kit the cost of memory and the CPU cores won’t kill the project. So am I nuts for trying or not? Heck no, we’ll learn a lot and I’m sure prices will drop and capacities will rise without sacrificing on performance.

Really, the price isn’t that bad. Just look on Amazon for the cheapest pricing of Intel 750 series NVMe disks of 1.2 TB and come back.

clip_image002

Today you won’t be buying 20 of them anyway to put in a JBOD as those don’t exist yet. You’ll put one or 2 in 1 or more backup target servers to provide high performance backup storage.

clip_image004

Testing 64K 100% sequential writes with 8 worker nodes enabled … not too shabby

NVME disks have stellar IOPS and throughput at low latencies. If you ever wear them out they are cheap enough to swap out for a new one. They absolutely rock under concurrent use, with multiple sessions and heavy workloads. Their massive IO queues make them shine as server storage in many to one scenarios. So backing up many different Hyper-V nodes (clustered or not) concurrently and continuously throughout the day is a use case where they should rock. Just search for some of the reviews out there for details.

Do you need bigger sized NVMe disks and a bit more “enterprise grade” comfort? Look at the Intel 3700 series or equivalents. Simplistically these are the same family but the 750 series disk has been tuned to do better for workstation workloads. But even then most people won’t get to see their true capabilities. Anyway the 3700 are more expensive and the 2TB seize mark might be what pushes you to buy them. Compared to some OEM enterprise grade SAS SSDs you’re still getting a pretty good deal. In any case many workstations cannot even make the Intel 750 series break out in single drop of sweat. We can push them a bit more in server workloads.

If you need redundancy with local NVMe storage you have some options. You can make local NVMe disks redundant today via Storage Spaces if you want or mitigate the risk by using 2 and have to backup jobs protecting the same VMs to different targets.

clip_image006

The Intel 750 NVMe disk installed in a Dell R730 dual socket server

clip_image008

Booting the DELL R730 which provides sufficient resources to evaluate the capabilities of an NVMe disk.

I cannot share to much info on this yet but look at the screenshot below. The VMs run on Storage Spaces (pure SSD) and the backup Target is the Intel 750 1.2 TB NVMe disk.

When the delta in the VMs is low, the amount of data you’ll need to backup with Veeam and Windows 2016 CBT is minimal so backup target performance is not that a big deal. But when you have bigger delta’s and multiple backup jobs running simultaneously that becomes a point that requires attentions.

clip_image010

Look at the above screen shot of some tests backing up VMs on Storage Spaces (Windows Server 2016) ReFS v3 source storage to NVMe with ReFS v3 target storage. Continuously protecting a company’s gold doesn’t have to cost you a king’s ransom in diamonds. We’re running Windows Server 2016 TPv5 and Veeam backup & Replication 9.5 Beta. I hope to discuss the capabilities of Windows Server 2016, ReFS and Veeam Backup and Replication 9.5 in later posts.

What will that cost me?

So let’s say you need 2 TB of backup storage in your backup target for your “always on” mission critical, state full virtual machines. For under 1600 € you can have that in Intel NVMe 750 Series. Today this really is not the technology to build a 300TB backup capacity solution with but when used for the right reasons in the right place with the right use cases this is a good solution.

Now, this isn’t the cheapest per GB, far from, but it is the absolutely best offering when with comes to fantastic throughput even, or better, especially when hitting that target storage with multiple concurrent backups from multiple sources. That’s where its shines beyond anything we have today. The real challenge there will be for the other resources to keep up as well as for the operating system and backup software to be capable of delivering what the NVMe disk(s) can handle. Compared to the OEM prices for their enterprise SAS SSD’s this is still reasonable.

We’ll compare this to “standard” SSD with controllers and see where this gets us. You can learn whether this works for you at relatively low cost, gain experience (i.e. find the bottle necks in the rest of your stack) and deliver a great result for the workloads you’re testing it with. Good backup software lets you fine tune the backups and even throttle backups based on latency of the source storage so you don’t have to worry about it killing the performance of your primary workloads.

Disclaimer: Don’t run of to your boss telling her or him I told you do implement NVMe backup storage targets. Only do so if you have a use case for this and are willing to try it out. Heck, I bought one on my own dime. So I could try it out and see if we can leverage this. If not, I have a great use case for the disk in my workstation for all those Hyper-V virtual machines.

For those 20 ultra-special stateful virtual machines in an “Always-On” environment … this might be the current solution. And please think beyond backups, think recovery of those virtual machines!

clip_image012

It’s kind of cool to use Veeam’s Instant VM recovery when the backup resides on an NVMe.

The future

Today, even with the NVMe Fabric v1.0 specifications published recently we don’t yet have “NVMe JBODS” or fabrics we can buy as commodity components but I’m rather sure those will come soon. These are interesting times and I’ll keep a keep a keen eye on the evolutions around NVMe.

Until then I’ll leverage commodity SSDs for landing the short term backups of VMs. When speed & frequency of those backups become crucial I’ll add a one or more NVMe disks to the mix.

I can put long term backup to other backup targets either via different jobs that run at night and/or via copies.

On top of all this the availability of 7.5 and 15 TB 3D NAND disks are about to change the way we look at high capacity disk based storage solutions. Those capacities in small form factors provide tremendous opportunities to deliver high capacity and performance in small building blocks making the power & cooling economics significantly better. Needing half a rack or a full rack of 3 or 6TB HDD to get both capacity & IOPS doesn’t seem that attractive anymore looking at the TCO over 5 years compared with 2 disk bays full with 7.5 or 15TB SSDs. In the future, with the rise of high capacity SSDs and dropping prices we might soon find that ever bigger SSDs deliver the bulk of our storage & NVMe is reserved for the truly demanding workloads.

Slowly but surely we can put most businesses in my country in one or half a rack without compromising in anything or needing to by vendor lock in converged solutions to make it happen. The scenario where we deliver on premises where it makes the most sense and move to the public cloud where it matters the most is more and more cost effective for those that can’t make data center zero happen yet. Combine that with a software defined approach and you’re looking good.

(*) I had a discussion about using NVMe for certain backup loads with some data center architects recently and they were convinced it was too expensive, too early and needed a consulting engagement leading to a POC to determine if this was a good idea. That would involve project & administrative costs, time and materials etc. Well, we just bought a couple of NVMe disk with on our own budget to test out the idea and concept. It works and is affordable for the right use cases. Just make sure you don’t put an NVMe disk in an anemic budget server where all other resources will be the bottle necks. Also make sure you have the intra host bandwidth to deliver the throughput. Last but not least, it’s pretty silly to have super performant backup targets when your backup source storage can’t deliver the data fast enough. Use common sense and you’ll be alright. It doesn’t need to cost you 10K to find out if buying 800 or 1600 € of NVME storage will work for you. If it seems to work, we can drop 2TB worth of NVMe storage in 3 backup target servers for under 4800 €. Using that in production for 6 months will teach us more than an expensive POC anyway.

The Hyper-V Processor Relative Weight

Introduction

Hyper-V offers 3 ways of managing or tweaking the CPU scheduler to provide the best possible configuration for certain scenarios and use cases. The defaults normally work fine but of certain conditions you might want to tweak them for the best possible outcome.  The CPU resource controls at your disposal are:

  • Virtual machine reserve  – Think of this as the minimum CPU “QoS”
  • Virtual machine limit – Think of this as the maximum CPU “QoS”
  • Relative Weight – Think of this as the scale defining what VM is more important.

Note that you should understand what these setting are and can do. Threat them like spices. Select the ones you need and don’t overdo it. They’re there to help you, if needed you can leverage all three. But it’s highly unlikely you’ll need to do so. Using one or two will server you best if and when you need them.

In this blog post we’ll look at the relative weight.

Relative weight

Relative weight is a relative number between 1 and 10000 that you can assign to a virtual machine. This determines the relative importance of a virtual machines CPU resources in regards to other virtual machines. So it’s not a % or number of cycles, it’s just a arbitrary weight. By default this is set to 100.


You need to come up with a scale and stick to it. 100, 200 and 300 for low, medium and high important virtual machines is a good example. You could also create 10 “classes”  1000, 1500, 2000, 2500, 3000, 3500, 4000, 4500, 5000, 5500. This leaves room to even create even more (lower, in between and higher).

Note that as long as there are sufficient CPU resources on a host the relative weight does not come into play. It really doesn’t matter whether a virtual machine has relative weight of 1000 versus 5000 at that time. They both get whatever they need as there’s plenty to go around.

Relative weight kicks in when the demand is higher than the availability on a physical host. When you have left all the virtual machines at the default of 100 they will all get an equal share. But when you’ve set virtual machines with a higher relative weight these will be getting a higher share of the available CPU cycles.

Use Cases

Not all virtual machines are created equal. In reality some workloads are more important than others. This might be development and test versus production or high priority workloads versus lower priority workloads. The lower priority workloads are the once that you care about less when there is contention for CPY cycles. Or workloads where less CPU cycles and slower response times don’t make a real difference.

Another use case might be on your developers or lab host where you have a CPU sensitive workload you give a much higher weight and leave the others at the default of 100.

To make sure the high priority workloads or those that really depend on more CPU cycles being delivered fast don’t have to play second fiddle to those that don’t have those needs we use relative weight. It’s very flexible and only kicks in when needed, so there is no waste or inefficiency there.

Limitations

The biggest limitation is in the name. It’s all relative. Where as reserve or limit give you a minimum and a maximum respectively, the relative weight only defines what virtual machine more important than another in regards to CPU cycles. So some virtual machines get more than others but that might not be enough. It’s all about balance between virtual machines, not guaranteed minima or maxima.

You need to agree on a standard within the company to define weight. If everyone starts using a different scale you’re in trouble.

Let’s take one admin who uses 100 for less important virtual machines, 200 for standard virtual machines and 300 for the most important ones. That’s all great when he’s the only one defining the settings and when he does so consistently on all nodes/ cluster for all VMs. In that case all is well even when VMs move around between hosts or between clusters. But what happens when many admins use different “scales”. Well it’s a mess and the behavior won’t be what you want when your colleague used 1000, 2000 and 3000 respectively for the same definition. It’s also smart to not use 100, 101 and 102. leave some margin for adding a category when needed.

Conclusion

This is one handy tool to have at your disposal and I tend to use it to proactively set a higher weight for very important VMs. Even in an environment where there are no predefined categories or know minima this allows me to tell Hyper-V that, if there ever is contention for CPU cycles, the virtual machines with a higher weight are the one to serve a bigger share of the limited resources.

The Hyper-V Processor Virtual Machine Limit

Introduction

Hyper-V offers 3 ways of managing or tweaking the CPU scheduler to provide the best possible configuration for certain scenarios and use cases. The defaults normally work fine but of certain conditions you might want to tweak them for the best possible outcome.  The CPU resource controls at your disposal are:

  • Virtual machine reserve  – Think of this as the minimum CPU “QoS”
  • Virtual machine limit – Think of this as the maximum CPU “QoS”
  • Relative Weight – Think of this as the scale defining what VM is more important.

Note that you should understand what these setting are and can do. Threat them like spices. Select the ones you need and don’t overdo it. They’re there to help you, if needed you can leverage all three. But it’s highly unlikely you’ll need to do so. Using one or two will server you best if and when you need them.

In this blog post we’ll look at the virtual machine limit.

Virtual Machine Limit

The virtual machine limit is a setting on the vCPU configuration of a virtual machine that you can set to limit the % of CPU resources a virtual machine can grab from the host. This setting limits the vCPU, preventing it to use more than the defined maximum percentage. The default percentage is 100.

Let’s look at some examples below based on a simple 4 core host with a VM.

On a 1 vCPU virtual machine with a virtual machine limit of 100% this means it can grab the equivalent of compute time slices of maximum 1 CPU on the host. Which is 25% of the total system CPU resources


So in case of a home lab PC that has 4 cores you can see that setting the virtual machine limit to 100% means it’s limited to 100% of the total system CPU resources.


When I set the number of vCPUs to 2 this drops to 50% of the total system CPU resources.


Now by playing with the virtual machine limit you can configure the desired maximum of the total CPU system resources a VM can grab. A 2 vCPU VM with 60% as a virtual machine limit get 30% of the total system CPU resources at the most on 4 CPU host.


Use cases

When you’re worried about run away virtual machines due to either misbehaving applications or developers who tend to run CPU stress tools in the guest and you really want to cap them to a certain limit without reducing the number of vCPUs (which they might need for testing parallelism, NUMA awareness) this might be a tool to use.

Limitations

This setting is always enforced. Even if a host has 32 cores and is only using 40% of them, a virtual machine could consume more CPU cycles without causing issues it won’t be able to. It’s a hard cap that’s always enforced.

The setting is enforced per vCPU. This means that when a single threaded app in a 4 vCPU virtual machine consumes the virtual machine limit it is capped even when the 3 other vCPU are totally idle.  So it’s not 30% of all vCPUs is 30% per vCPU maximum.

Conclusion

It’s a tool you have at your disposal but it’s probably the least used one. It has limited uses case due to it’s limitations. For most scenarios you’re better of leveraging virtual machine reserve or the relative weight. These are more flexible and are only enforced when needed, providing a smarter use of resource.

Discrete Device Assignment with Storage Controllers

Discrete Device Assignment with Storage Controllers is the second type of DDA we’ll look at. I have written before on Discrete Device Assignment in Windows 2016. A the time of writing officially the 2 supported use cases are GPU and NVMe disk pass-through. I have demonstrated the configuration of DDA with a NVIDIA GRID K1 GPU here.

Meanwhile I have also successfully configured DDA with a NVMe disk. I’ll demonstrate how to do this later but in this blog post I want to address a consequence of this experiment. So let’s take a preliminary at Discrete Device Assignment with storage controllers

With an Intel NMVe disk you do not assign the actual disk to the virtual machine. It’s the controller. By disabling and dismounting the standard NVM Express Controller from the host and assigning it to the guest you make the NVME disk available in the guest.


This is supported. This makes me wonder if MSFT would consider officially supporting other storage controllers. What if you need 8TB of high performance storage dedicated to a single VM? You could assign an extra controller in the host with a RAID 10 SSD virtual disk to the virtual machine. How different would that be from NVMe? No too much I guess. Smile

https://i0.wp.com/blog.workinghardinit.work/wp-content/uploads/2016/04/image-7.png?ssl=1

By the way this assigning & un-assigning keeps data intact. This means that is also a roundabout sort of way to get data in and out of a virtual machine. On of the funky, crazy ideas I have already is to use this to export & import data. Maybe.

I really do wonder how things will evolve here. Perhaps these are too much “niche” use case scenarios but it’s interesting none the less. But perhaps the advances in NVMe Fabrics and the added performance available via VHDX outpace the need for DDA storage solutions.

Anuway enough musing as we’ll be taking a more hands on look at assigning a NVMe disk to a VM and Discrete Device Assignment with storage controllers via PowerShell in a later blog and video.
